Nickel Alloy Nimonic 90 UNS N09901
HY N90 相似牌号:
Nimonic 90/GB GH90/ UNS N07090 / BS Nimonic90/ W. Nr. 2.4632
HY N90的化学成分
合金 |
% |
钴 |
铬 |
镍 |
铁 |
锆 |
硼 |
碳 |
锰 |
硅 |
硫 |
磷 |
铜 |
铝 |
钛 |
HY N90 |
最小 |
15.0 |
18.0 |
余量 |
1.0 |
2.0 |
|||||||||
最大 |
21.0 |
21.0 |
1.5 |
0.15 |
0.02 |
0.13 |
0.14 |
0.8 |
0.015 |
0.02 |
0.2 |
2.0 |
3.0 |
HY N90的物理性能
密度 |
8.2 g/cm3 |
熔点 |
1400℃ |
热导率 |
21.76λ(100℃) |
弹性模量 |
GPa |
HY N90在常温下合金的机械性能的最小值:
合金 |
抗拉强度 |
屈服强度 |
延伸率 |
σb/MPa |
σp0.2/MPa |
σ5 /% |
|
固溶处理 |
820 |
590 |
8 |
HY N90的特性和应用领域
该合金是时效强化钴镍基变形高温合金,该合金在815~870℃有较高的抗拉强度和抗蠕变能力、良好的抗氧化性和耐腐蚀、在冷热反复交替作用下有较高的疲劳强度以及良好的成形性和焊接性。用于涡轮发动机涡轮盘、叶片、高温紧固件、卡箍、密封圈及弹性元件等。
HY N90的金相组织结构
该合金主要强化相是γ’-Ni3(Ti、Al),在晶内以大小不同的方形颗料关析出,在晶界上也可以见到这种形状的γ’相,碳化物在晶界上呈不连续的链状析出。
HY N90的工艺性能与要求
1、合金在锻造时易产生内裂,允许重锤打击。刚锭装炉温度不高于700℃,低温区域先预热20-30分钟,最终加热温度1150℃-1180℃,开锻温度不低于1050℃,终锻温度不低于950℃。
2、该合金的晶粒度平均尺寸与锻件的变形程度、终锻温度密切相关。
3、合金在固溶状态可进行惰性气体保护钨极电弧焊及闪光对焊。
生产标准:
棒材;丝材 |
BS HR2 Nimonic 90 bars, billet, forgings;BS HR501 Nimonic 90 cold drawn wire for springs;BS HR502 Nimonic 90 cold drawn and solution; treated wire for springs;BS HR503 Nimonic 90 wire for thread inserts;AMS 5829;AECMA PrEN 2295;AECMA PrEN 2296;AECMA PrEN 2297;AECMA PrEN 2400;AECMA PrEN 2401;AECMA PrEN 2669;AECMA PrEN 2670;MSRR 7016;MSRR 7137;Siemens DL 1641-1;ABB Stal 63 73 01 |
板材;带材 |
BS HR202 Nimonic 90 sheet and strip;MSRR 7087;AECMA PrEN 2298;Siemens TLV8525 2100;Siemens TLV8525 31001 |
管材 |
BS HR 402;AECMA PrEN 2299 |
各类合金的常用规格 | |||
Form | Specification | Supply Form | Others |
Sheet | Thickness:0.40-4.75mm,General Width:1000、1219、1500mm | Whole Coil or piece of it | Cold Annealed,Surface 2B、2E |
Plate | Thickness:4.76-60mm,Width:1500、2000、2500mm,Length:3000、6000、8000、8500mm(Under 10mm plate can be coiled) | Whole Coil or piece of it | Single hot rolling,Solid solution annealed state,Surface 1D |
Belt | Thickness:0.10-3.0mm,Width:50-500mm | Whole Coil or Specified size | Cold Annealed,Surface 2B、2E |
Bar & Rod | Rolled barΦ5-45mm,Length≤1500mm | Polished Bar(circle、Square) | Solution annealing,descaling |
Forged barΦ26-245mm,Length≤4000mm | |||
Weld tube | Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm | Base on your requirement | |
Seamless Tube | Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm | Base on your requirement | |
Wire | Outer diameterΦ0.1-13mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Forged piece | discs,rings,squares,blocks,slabs | Base on your requirement | Steel, Alloy |
Flangs | All kinds of Flangs | Base on your requirement | Steel, Alloy |
Welding Material | Coil wire Φ0.025mm-1.6mm | Base on your requirement | Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France. |
Straight WireΦ1.6mm-4.0mm | |||
Welding rodΦ1.2mm-4.0mm | |||
Tube | Elbow, three links, four links, different diameter size | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Explosive bonded laminate | Raw Sheet Thickness≥2mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
